| Technical Parameters | |||
|---|---|---|---|
| Item | DC Type | AC 5-wire (Built-in Relay) | AC 2-wire |
| Operating Supply Voltage | 10~30VDC | AC90~250V, AC380V | |
| Current Consumption | ≤18mA | ≤35mA | ≤1.8mA |
| Output Current | ≥200mA | 50mA, 3A | 300mA |
| Emitter Current | ≤15mA | ≤10mA | |
| Rated Sensing Distance | 2.5mm～10m (Depends on housing dimension) | ||
| Detectable Object | Transparent or opaque objects | ||
| Response Time | 2.5ms～100ms | ||
| Ambient Illuminance | Sunlight ≤10000LX, Incandescent Lamp ≤3000LX | ||
| Ambient Temperature | Storage: -25℃~+75℃; Operating: -15℃~+55℃ | ||
| Ambient Humidity | Storage: 35%~95%RH; Operating: 45%~85%RH | ||
| Withstand Voltage | 1.5kV, 50Hz/60Hz, 1min | ||
| Vibration Resistance | 10～50Hz, double amplitude 1.5mm, 1 hour | ||
| Ingress Protection | IP60~IP67 | ||
