Capacitive Level Transmitter

Capacitive Level Transmitter

$35.00

Applications
Threaded connections starting from ½“, G1” universal connection for sanitary adapters, M12, solenoid valve plug, transistor output, sanitary approval
The ESPCM-2A is a cost-effective level switch designed for detecting light bulk solids. Users can opt for the universal interface for sanitary adapters, which fully meets the requirements of sanitary processes in the food, beverage, and pharmaceutical industries while saving on installation costs and reducing spare parts inventory. The instrument is ready for use without calibration.

SKU: ESPCM-1A with 2-meter cable, ESPCM-2A with integrated cable 分类: , 品牌:

描述

Applications
Used for measuring solid and granular materials. Zero and full-scale calibration must be performed with material present.

Technical Specifications
Name NPN (NO+NC) PNP (NO+NC)
Model ESPCM-1N ESPCM-1P
Delay ±1mm
Repeatability ±1mm
Response time 0.1s,typ.0.2s,max.
Output Type Adaptive (PNP/NPN)
Switch Logic Adaptive Normally Closed (NC)/Normally Open (NO)
Process Interface M12 Thread
Materials of Contact Components PEEK, 304 stainless steel
Housing Material 304 Stainless Steel
Supply voltage 5…30VDC
Wiring Protection Reverse-phase protection, overload protection, short-circuit protection
Enclosure Protection Rating IP67
Temperature -40~85℃
Current consumption <25mA
